Plain Roller Crusher

Product description

What is Plain Roller Crusher

The Smooth Double Roll Crusher is a kind of machine which is extended by the spring Double Roll Crusher. The advantage of hydraulic structure is that it can control the pressure between two reliefs accurately. Long-term continuous operation can still guarantee the crushing pressure between two rollers. Therefore, the equipment of roller crusher in the grinding system can give full play to the production capacity of the grinding equipment. Generally, the output can be increased by 30%~40%, and the total energy consumption can be reduced by 20%-30%.

Plain Roller Crusher Suitable Materials

River pebbles, calcite, quartz, glass, marble, cobblestone, bentonite, iron ore, bluestone, mountain rock, limestone, weathered sand, diabase, granite, basalt, and other materials for crushing and sand-making.

Why Choose Huashengming ?

1.Superior to Hammer Crushers: No need for frequent replacement of vulnerable parts.

2.High-Quality Sand: Produces well-rounded sand particles with rational grading, low over-crushing rate, and high output.

3.Advantages Over Hammer/Impact Crushers: Roller sleeves have an average service life of over 2 years.

4.Patented Technology: The high chromium manganese steel wear-resistant roller skin (national patent), precise discharge adjustment system (national patent), and roll design (national patent) ensure optimal performance.

Performance advantages:

1. Superior Product Shape: Minimal over-crushing.

2. Adjustable Discharge Size: Simple and precise control.

3. Non-Clogging Design: Optimized structure avoids blockages.

4. Dual Motors: Powerful and reliable.

5. High Durability: Rollers made of patented manganese steel for extended lifespan.

6. Cost-Effective: Low investment and operating costs.

Choosing the right crushing equipment is essential for producing quality sand and gravel. The double roller crusher offers high efficiency, low energy consumption, and superior product quality. For sand and gravel producers, this equipment enhances competitiveness and meets market demands.

If you need a reliable crusher, consider the double roller crusher. It boosts your production line’s efficiency and output stability. Huashengming Heavy Industry offers top-quality double roller crushers. Contact us for more details.

working principle

The double roll crusher uses two independently driven rollers that rotate in opposite directions, generating extrusion and shearing forces to crush materials. Feed material enters through the inlet, is crushed by the rollers, and discharged naturally. If unbreakable or oversized materials are encountered, the hydraulic cylinders or springs automatically retract the rollers to widen the gap, allowing the material to fall through safely. The discharge size is adjusted by controlling the hydraulic or spring pressure.

Technical parameters

• Founded in 2008Serving millions of users over the years
• Customized ServiceCustomized crushing solutions for consumer needs
• Tailored ProductionSupporting customers to put into science-based production
• Routing InspectionQuick resolution of after-sales issues
